Graham-Field Lumex Bariatric Easy Sit-To-Stand Lift

Graham-Field Lumex Bariatric Easy Sit-To-Stand Lift

  • Made in USA

Graham-Field Lumex Bariatric Easy Sit-To-Stand Lift is designed to provide quick, safe assistance to those with lower strength who have trouble standing. The Sit-to-Stand Lift is designed for individuals who find it difficult to support the majority of their own weight. Bariatric Easy Lift is easy to maneuver and has a low base that can fit under most beds, making it a great choice for in home use. The 24V DC motor easily pulls patients from a seating position to standing. A hand pendant controls the Lift Stand and has hooks to hang on the Lift frame for easy storage.

Bariatic Easy Lift STS Highlights:

  • Adjustable knee pad
  • Comfortable
  • Easily maneuvered
  • Emergency lowering device
  • Emergency stop button
  • Large easy-grip handles

Item # Desc Pkg Reward Price
LF2090 Lumex Bariatric STS Lift Each $81.46
$2986.99
$2715.39

Lumex Easy Lift STS Features

  • Heavy-gauge steel construction
  • Unique, ergonomic foot pedal base opening
  • Large, easy to grip handles for easy maneuvering
  • Lower base height maximizes stability and fits under most beds
  • Rubber base coating protects furniture and walls
  • Adjustable knee pad unit
  • Quick release removable foot platform
  • Ergonomically designed hand pendant with pendant hook
  • Warning beep for low battery charge and weight capacity levels
  • Interchangeable battery works with other Lumex Easy lifts
  • Easy access emergency stop button
  • White powder-coated finish
  • 24V DC motor allows quiet, smooth operation
  • Accessory storage bag included for slings and charger
  • Maximum weight capacity: 600lbs
  • Also Available Separately:
     - Graham-Field Lumex Charger Unit for Single-Pin Connection                         -Graham-Field Deluxe Sit-to-Stand Padded Slings
  • Lumex Bariatric Easy Sit-To-Stand Lift User Manual

More About Bariatric Easy Lift STS

Assembly Instructions:

  • Remove the nuts and bolts from top and bottom of mast
  • With one hand on the mast and another on the boom, pull the mast to an upright position Reinstall the bolts in the holes at bottom of mast and hand tighten them
  • Attach boom to mast and hand tighten bolt and nut
  • Attach the L-shaped arms to the back of the knee pad
  • Attach knee pad assembly to the mast
  • Place the control box in the bracket
  • Insert the actuator plug into the control box
  • Insert the pendant plug into the control box
  • Tighten all nuts


Warning:

  • Before using Patient Lift, ensure that lift is assembled as described, that all attaching hardware is securely tightened, and that all lift components are secure

Warning WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Specification

Particulars Dimensions
Floor clearance 4.7"
Spreader Bar Minimum Height from Sling Attachment 36.4"
Spreader Bar Maximum Height from Sling Attachment 70.8"
Overall length 40.4"
Minimum Base Width (Outside) 25.5"
Maximum Base Width (Outside) 37.8"
Maximum Weight Capacity 600 lb Evenly Distributed
Product Weight 134 lb



Warranty

Frame and spreader bar three-year limited warranty
